LAMPING Number of Bulb: 1 Light Type: LED Bulb Type: DC Integrated Bulb Max Wattage: 14 Total Wattage: 14 Lighting Direction: Omni Install Up/Down: Any Rated Life: 25,000 Hours Rated Lumens: 1400 Delivered Lumens: 880 Color Temperature: 3000 K Bulb(s): Integrated CRI: 90 Dimmable: Triac or ELV at 120V Input Voltage: 120-277
MEASUREMENTS Width: 6.75" Height: 6.75" Extension: 1.25" HCO: 3.5" BP Width: 4.5" BP Height: 4.5" Wire Length: 8" Hanging Weight: 1.6 lb. UPS Shippable: Yes
CERTIFICATIONS/ OTHER Safety Rating: Wet ADA Compliant: Yes Finish: White Material: Aluminum
View Hi-Res Image
Specification Sheet
Assembly Instructions
Photometric
Parts and Accessories
Schematic Diagram
MAIN
Bottom
Top
